Product Details
| 40英尺骨架半挂车技术规范配置 / Technical Specification of 40FT Container Chassis 型号 Model：GN40M2LAM00 | ||
| 技术规范内容 Specification（中英文对照） | ||
| 总体参数 Overall parameters | 产品描述 Product description | 40英尺二轴骨架半挂车 40ft Container Chassis with 2-axle |
| 功能 Function | 1×40FT集装箱 1x40FT container | |
| 外轮廓尺寸 (mm) Overall dimension (mm) | 12,460×2,480×1,605（高度可根据牵引车调整） 12,460×2,480×1,605 (The height will be adjusted according to the tractor specification) | |
| 轴距 (mm) Wheel base (mm) | 9,542 + 1,310 | |
| 净重 (kg) ±3% Tare weight (kg) | 约3,900 Approx. 3,900 | |
| 最大载质量 (kg) Max. payload (kg) | 30,500 | |
| 总质量 (kg) G.V.W.R. (kg) | 34,400 | |
