Specifications
Main SpecRated Load5500kg
Operating Weight17040kg
Rock Bucket3.3 m3
Total Cycle Times10.6s
Max Traction Force160kN
Max Breakout Force165kN
Power systemModelWD10G220E23
Rated power162kW/rpm
Rated speed2000r/min
Specific fuel consumption of the rated conditions220g/kW·h
Fuel tank capacity320L
Walking systemTracel speed range (F)0-42km/h
Tracel speed range (R)0-17.5km/h
Steering angle37°±1°
Tire model23.5-25/16PR/L-3
Hydraulic systemWork system pressure18Mpa
Work system displacement100ml/r
Steering system pressure16Mpa
Steering system displacement152ml/r
Hydraulic oil capacity210L
Overall DimenssionsDimensions8360╳2980╳3380mm
Wheel base3300mm
Wheel tread2150mm
Min ground clearance440mm
Min Radius outside the bucket7020mm
Dump height3100mm
Dump reach1160mm
