Product Details

Specifications
Main SpecOperating Weight25050kg
Boom length5850mm
Arm length3050mm
Bucket capacity1.2m3
Power systemModelCC-6BG1TRP
Rated power128.5kW/2100rpm
Specific fuel consumption of the rated conditions237g/kW·h
Fuel tank capacity385L
ChassisFrame rail distance2580mm
Wheelbase3845mm
Width of track shoe600mm
Track length4660mm
PerformanceBucket breakout force147/160kN
Stick breakout force106/116kN
Travel speed3.7/5.4km/h
Swing speed12.2rpm
Max tracion force217kN
Groundability35°
Ground pressure49kPa
DimenssionsOverall dimenssion9890╳3180╳3280mm
Max digging height10190mm
Max unloading height7220mm
Max digging depth6845mm
Max digging radius10190mm
Max swing Radius2920mm
