Product Details

Specifications
Main SpecOperating Weight33600kg
Boom length6470mm
Arm length3190mm
Bucket capacity1.5m3
Power systemModelAA-6HK1XQP
Rated power190.5/2000kW/rpm
Specific fuel consumption of the rated conditions237g/kW·h
Fuel tank capacity664L
ChassisFrame rail distance2590mm
Wheelbase3700mm
Width of track shoe600mm
Track length4630mm
PerformanceBucket breakout force205/223kN
Stick breakout force155/169kN
Travel speed4.9/3.0km/h
Swing speed9.2rpm
Max tracion force257kN
Groundability35°
Ground pressure68kPa
DimenssionsOverall dimenssion11234╳3205╳3343mm
Max digging height10105mm
Max unloading height7075mm
Max digging depth7345mm
Max digging radius11075mm
Max swing Radius4371mm
